HAAS VF2SS

  • 12,000 RPM Inline Direct Drive Liquid Cooled Spindle

  • Machine Travel 30"x16"x20"

  • 1,400 IPM Rapids

  • 833 IPM Cutting

  • 30+1 Tool capacity

  • 2.4s Chip to Chip

  • High Speed Side Mount Tool  Changer

  • Renishaw WIPS System

  • Haas NexGen Controller

  • Chip Auger

  • Auto Air Gun

  • 60psi Coolant System


FADAL VMC 15-XT (2x)

  • Machine Travels 30" / 16" / 20"

  • Table Capacity: 1500 Lbs.

  • Spindle Taper: Cat 40 Taper

  • Spindle Speeds: 7,500 RPM

  • Rapid Traverse Rate 400 IMP

  • Maximum Cutting Feed Rate: .01" - 250" IPM

  • Tool Changer Style: Carousel

  • Tool Changer Capacity: 21 Stations

  • Max Tool Weight: 15 Lbs

  • Spindle Drive: 15 Hp

  • Spindle to Table Distance: 4" - 24"

  • Spindle Center to Column Distance: 17"


FADAL VMC 4020 (2x)

  • Fadal CNC 88 HS Control

  • Fadal 4th Axis Rotary Table

  • 21 Tools Changer

  • Box Way Design

  • High Torque Spindle

  • High Speed Cpu

  • Usb Port

  • 2-speed Gear Box

  • Extended Memory

  • Machine Travels  40" / 20" / 20"

  • Rapid  900 IMP

  • Cutting Feedrate: 400″ IMP


BRIDGEPORT TC-22
(5X)

  • Table Size 32" X 16"

  • Spindle Nose To Table Top 4.33" To 24.33"

  • X-axis Travel22"

  • Y-axis Travel16"

  • Z-axis Travel20"

  • Automatic Toolchanger 22 Positions

  • Throat Depth 17.7"

  • Spindle Taperbt-40

  • Spindle Speeds (2 Gear Ranges)6,000, 7,500 Rpm

  • X Axis Rapid Traverse Rate472 Ipm

  • Y Axis Rapid Traverse Rate472 Ipm

  • Main Motor7.5 Hp

  • Dimensions 79" X 79" X 96"

  • Weight 6,500 Lbs.

  • Electrics 208 V / 60 Hz
